6685-00-239-9295
Description: Dial Indicatin Differential Gage

Price Quote
Quality Assurance
We are commited to quality and satisfaction as a certified supplier in the aerospace and military industries.
- Certificate of Conformity
- QC Inspection prior to shipping
- On time delivery
- International Shipping Available
- Friendly service to back every order
Export Restrictions
Any part(s) quoted or sold by MilSpec.parts and re-sold (to a third party) CANNOT be sold to a USA embargoed country, company, entity, or person(s). Depending on the ECCN, these commodities may require export license or exception. Diversion contrary to U.S. law is prohibited. Unless otherwise noted, this sale, order or quote may include Munitions List Items (MLI) or Commerce Controlled List Items (CCLI). MLI/CCLI property is controlled by the US Government and in many cases cannot be transferred (exported, sold or given) to a foreign country, a non-US Citizen/National or a non- Permanent US Resident without a valid State/Commerce Department export authorization. It is the responsibility of (the Purchaser) to determine what the applicable requirements may be, to obtain all necessary authorizations, licenses or approvals and are subject to both review and acceptance by MilSpec.parts. The use, disposition, export and re-export of the property covered or included in this sale, order or quote is subject to the provisions of law referenced in End-Use Certificate DLA form 1822, DEC 2001, including, but not limited to, the Arms Export Control Act (22 USC 2751 et seq.); Export Administration Act of 1979 (50 USC App. 2401 et seq.) as contained under Executive Order 12924; International Traffic in Arms Regulations (22 CFR 120 et seq.); Export Administration Regulations (15 CFR 730 et seq.); Foreign Assets Control Regulations (31 CFR 500 et seq.) and the Espionage Act (18 USC 793 et seq.)
6685-00-239-9295 Properties
-
NSN:6685-00-239-9295
-
Description:Dial Indicatin Differential Gage
-
Shelf Life:N/A
-
DEMIL:NO
-
UOM:1 EA
-
Overall Depth:2.188 inches
-
Bolt Circle Diameter:4.125 inches
-
Mounting Hole Diameter:0.188 inches
-
Mounting Hole Quantity:3
-
Overall Diameter:4.750 inches
-
Case Material:Aluminum
-
Case Surface Treatment:Enamel, baked
-
Accessory Components And Quantity:Adapters flush mtg w/screws 3; adapters 1/8 in. Pipe to rubber tubing 2; nut-jam 1; plugs 1/8 in. Spt 2; stud back mtg 1; washers 2
-
Graduation Unit:0.20 inches
-
Actuation Type:Diaphragm
-
Adjustability:Adjustable
-
Scale Range:+0.0 to 1.0 inches of water
-
Scale Name:Inches of water
-
Dial Size:3-7/8 in. Dia
-
Connection Quantity:4
-
Pointer Color:Black and red
-
Pointer Type:Indicating
-
Scale Marking:Inches of water
-
Scale Type:Dial
-
Scale Smallest Increment:0.02 inches
-
Connection Type:External
-
Mounting Method:Hole or stud
-
Stud Quantity:1
-
Scale Accuracy:2 pct accuracy rating entire range
-
Actuating Element Material:Silicone rubber
-
Scale Inscription/background Color:Black figures on white background
-
Scale Name For Which Pointer Is Designed:Inches of water
-
Connection Location:Back and side
-
Bezel Type:Thread
-
Protective Crystal Material:Plastic
-
Connection Size:All connectors 1/8 in. Spt
-
Mounting Connection Location:Back
-
Stud Location:Back
-
Connector Type Vent:Not provided
-
Material:Aluminum
-
Material:Aluminum
-
Surface Treatment:Enamel
-
Surface Treatment:Enamel, baked
